2013
International Conference on Crystalline Silicon Photovoltaics SiliconPV 2013)

Lifetime Measurements on Attached Epilayers and Detached Epifoils Grown on Reorganised Porous Silicon Showing a Bulk Lifetime Exceeding 100 μs

Header image

Abstract

This paper discusses on-going efforts towards reliable lifetime measurements on epilayers and the subsequent decoupling of the bulk and surface recombination components, both while it is still attached to the p+ substrate on which it is grown (“attached epilayer”) and after its detachment from the substrate (“detached epifoil”). For the “attached epilayers”, microwave photoconductance decay (^-PCD) and simulation-assisted photoluminescence (sim-PL) were applied together with a variation in the epilayer thickness to evaluate the bulk lifetime (Tbulk) and total effective surface recombination velocity (Stot) of p-type epilayers. By applying linear fits to reciprocal effective lifetime versus reciprocal epilayer thickness data, Stot of all samples were reliably extracted, resulting in Stot of ∼265 cm/s in the absence of porous silicon at the epilayer/substrate interface compared to ∼9220 cm/s when present and ∼775 cm/s when shielded by a thin back surface field. Based on these Stot values, sim-PL was used to estimate Tbulk to be ∼160 |us in the porous silicon area. For the n-type “detached epifoils”, quasi-steady state photoconductance (QSSPC) was used. However, reliable Tbulk could not be extracted, despite the lower Stot because Tbulk was too high. However, a lower limit to Tbulk was estimated to be >138 μs. Such high bulk lifetimes imply bulk diffusion lengths that are an order of magnitude longer than the epilayer thicknesses, potentially leading to high cell efficiencies.

Topic

epilayer, bulk lifetime, porous silicon, surface recombination velocity, Microwave Photoconductive Decay (μ-PCD), QSSPC, PL, PC1D

Author

H.S. Radhakrishnan, M. Debucquoy, F. Korsós, K. Van Nieuwenhuysen, V. Depauw, I. Gordon, R. Mertens, J. Poortmans
